| Camera |
| Max Resolution |
4 MP |
| Sensor |
1/2.9" CMOS |
| Min. Illumination |
Color: 0.005 Lux (F1.78, AGC ON), 0 Lux with IR |
| Day/Night |
IR-cut filter with auto switch (ICR) |
| Shutter |
Auto/Manual, 1 ~ 1/100000s |
| WDR |
120 dB |
| S/N |
>56 dB |
| Lens |
| Focal Length |
5.5 to 88 mm |
| Optical Zoom |
16X |
| Iris |
F1.78-F3.73 |
| Field of View (H) |
50.85° to 3.47° |
| Field of View (V) |
29.94° to 1.95° |
| Field of View (D) |
62.55° to 4.09° |
| DORI |
| DORI Distance (Detect) |
127.6 m to 2048.4 m (418.6 ft. to 6720.5 ft) |
| DORI Distance (Observe) |
51.0 m to 819.4 m (167.4 ft. to 2688.2 ft) |
| DORI Distance (Recognize) |
25.5 m to 409.7 m (83.7 ft. to 1344.1 ft) |
| DORI Distance (Identify) |
12.8 m to 204.8 m (41.9 ft. to 672.0 ft) |
| Video |
| Privacy Mask |
24 areas, up to 4 areas per scene |
| Video Compression |
Ultra 265, H.265, H.264, MJPEG |
| Frame Rate |
Main Stream: 4 MP (2688 × 1520), max. 30 fps
Sub Stream: 720P (1280 × 720), max. 30 fps |
| Video Bit Rate |
128 Kbps to 16 Mbps |
| U-code |
Support |
| ROI |
Support |
| Video Stream |
Dual streams |
| OSD |
Up to 4 OSDs |
| Intelligent |
| Auto Tracking |
Support, target filtering: human and vehicle |
| Smart Intrusion Prevention |
Cross line detection, intrusion detection (support false alarm filtering and the classification of human and vehicle) |
| Image |
| White Balance |
Auto, Outdoor, Fine tune, Sodium lamp, Locked, Auto2 |
| Digital Noise Reduction |
2D/3D DNR |
| Flip |
Normal, Flip vertical, Flip horizontal, 180° |
| HLC |
Support |
| BLC |
Support |
| Smart IR |
Support |
| Defog |
Digital defog |
| Events |
| Basic Detection |
Motion detection, Tampering alarm, Audio detection |
| General Function |
Watermark, IP address filtering, Access policy, ARP protection, RTSP authentication, User authentication, Alarm input |
| Audio |
| Audio Compression |
G.711U, G.711A |
| Audio Bitrate |
128 Kbps |
| Two-way Audio |
Support |
| Suppression |
Support |
| Sampling Rate |
16KHZ |
| Storage |
| Edge Storage |
MicroSD, up to 512 GB |
| Network Storage |
ANR, NAS (NFS) |
| Illuminator |
| IR On/Off Control |
Auto/Manual |
| Wavelength |
850 nm |
| Illumination Distance (IR) |
Up to 100m (328 ft) IR range |
| Network |
| Protocols |
IPv4, IPv6, IGMP, RTP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTSP, RTCP, RTMP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, 802.1x, SNMP, QoS, SSL/TLS |
| Compatible Integration |
ONVIF (Profile S, Profile G, Profile T, Profile M), SDK, API |
| User/Host |
Up to 32 users. 3 user levels: administrator, common user and operator |
| Security |
Password Protection, Strong Password, HTTPS Encryption, Export Operation Logs, Basic and Digest Authentication for RTSP, Digest Authentication for HTTP, TLS 1.2, WSSE and Digest Authentication for ONVIF |
| Client |
EZStation, UNV-Link, UNV-Link Pro |
| Web Browser |
Plug-in required live view: IE 10+, Chrome 45+, Firefox 52+, Edge 79+ |
| PTZ |
| Number of Presets |
1024 |
| Preset Patrol |
16 patrols, up to 64 presets for each patrol |
| Route Patrol |
16 patrols, up to 32 actions for each patrol |
| Recorded Patrol |
16 patrols, up to 128 actions for each patrol |
| Patrol Stay Time |
15 s to 1800 s |
| Home Position |
Support |
| Pan Range |
360° (endless) |
| Tilt Range |
-5° to 90° (auto flip) |
| Pan Speed |
0.1°/s to 240°/s |
| Tilt Speed |
0.1°/s to 120°/s |
| Interface |
| Audio I/O |
1 Input: impedance 1 kΩ, amplitude 2.5 V [p-p], 1 Output: impedance 600 Ω, amplitude 2.5 V [p-p] |
| Alarm I/O |
2/1 |
| Serial Port |
1*RS485 |
| Network |
1 × RJ45 10 M/100 M Base-TX Ethernet |
| Certification |
| EMC |
CE-EMC (EN 55032: 2015+A11:2020+A1:2020,EN IEC 61000-3-2: 2019+A1: 2021,EN 61000-3-3: 2013+A1: 2019+A2:2021,EN 50130-4: 2011+A1:2014)
FCC (FCC CFR 47 part15 B, ANSI C63.4-2014) |
| Safety |
CE LVD (EN 62368-1:2014+A11:2017)
UL (UL 62368-1, 2nd Ed., Issue Date: 2014-12-01) |
| Environment |
CE-ROHS (2011/65/EU;(EU)2015/863) |
| Protection |
IP66 (IEC 60529:1989+AMD1:1999+AMD2:2013)
IK10 (IEC 62262:2002) |
| General |
| Power |
DC 12 V (±10%, 3A), PoE+ (IEEE 802.3at) |
| Power Consumption |
Max. 23 W |
| Power Interface |
Ø5.5 mm coaxial power plug |
| Dimensions |
Ø167 mm × 181 mm (Ø6.6" × 7.1") (Ø × H) |
| Weight |
2.3 kg (5.07 lb) |
| Working Environment |
-40℃~65℃ (-40°F~149°F), Humidity: ≤95% RH (non-condensing) |
| Storage Environment |
-40℃~70℃ (-40°F~158°F), Humidity: ≤95% RH (non-condensing) |
| Surge Protection |
6 KV |
| Reset Button |
Support |
